Split AC Evvoli 12000 BTU, Inverter A++, Raffreddamento e Riscaldamento Rapidi, Gas R32 EVDC-12K-EU-1
Split AC Evvoli 12000 BTU, Inverter A++, Raffreddamento e Riscaldamento Rapidi, Gas R32 EVDC-12K-EU-1
Dimensioni
Caratteristiche
Inverter A++ per un risparmio energetico ottimizzato
Gas R32 ecologico
Flusso d'aria 3D per una migliore copertura della stanza
Rivestimento dorato delle alette per protezione dalla corrosione
Condividi
Contenuto comprimibile
Key FeaturesGas type R32 A++ Inverter 3D Air-Flow Self-Clean Auto Restart Golden Fin Fast Cooling and Heating Product SpecificationCooling (T1) Capacity Btu 12000 (4700~14700) Current A 4.37 (0.6~7.2) EER W/W 3.50 Cooling (T3) Capacity Btu - Current A - EER W/W - Heating Capacity Btu 13000 (3640~14950) Current A 4.24 (0.7~6.78) COP W/W 3.90 Rated Power Input W 2200 Rated Current A 10.5 Max. Air Flow Volume m3/h 520 Length of Pipe kit m 3 RefrigerantType R32 Charged g 620 Liquid piping mm Φ6.35 Gas piping mm Φ9.52 Max. Discharge Pressure Mpa 4.3 Max. Suction Pressure Mpa 1.7 | Indoor UnitEvaporator pipe Material Copper Evaporator bend Yes Evaporator row 2 Evaporator pipe diameter mm 7 Fan Motor ZKFP-13-8-4 Max. Noise dB(A) 39 Outdoor UnitCompressor Brand GMCC Compressor Type ROTARY Compressor Model KSN98D64UFZ3 Fan Motor ZKFN-34-10-1 Compressor Pipe Material Copper Condenser Row 1 Condenser Pipe Diameter mm 7 Max. Noise dB(A) 54.5 Power SupplyVoltage V 220-240 Phase Ph 1 Frequency Hz 50 Product and Packaging InformationIndoor Unit Product Dimension (WxHxD) mm 835x208x295 Package Dimension (WxHxD) mm 905x355x290 Net weight Kg 8.7 Gross Weight Kg 11.3 Outdoor Unit Product Dimension (WxHxD) mm 765x303x555 Package Dimension (WxHxD) mm 887x337x610 Net weight Kg 26.4 Gross Weight Kg 28.7 Shipping InformationContainer Loading (20FT/40FT/40HQ) Sets 99/208/239 Indoor CBM m3 0.09316975 Outdoor CBM m3 0.18234059 TTL CBM m3 0.27551034 |
